FTTH Drop Cable Production: Manufacturing Process Explained
Surprising fact: more than 70% of new U.S. broadband builds now use fiber networks that need high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment runs complete FTTH cable production line manufacturing, from choosing brand fibers like Fujikura or Corning SMF-28e to final test reports that guarantee full quality assurance.
Our drop designs are built for overhead, underground, and direct burial installation, with LSZH, polyvinyl chloride (PVC), and polyethylene (PE) jacket options and arrangements from 1–4 cores. We offer OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone-matched sheath colors, and custom logo printing.
Automation and high-precision equipment keep line speed steady and repeatability high. Typical lead times are 4–5 days for orders < 100 km and seven to ten days for < 500 km, with an MOQ of 1 km and free-replacement warranty for quality problems.
Continue to learn how our materials, tests, and support work together to reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment offers full manufacturing with lab validation for United States projects.
- Multiple jacket choices and optical grades support indoor/outdoor environments.
- Automated lines and machines deliver stable quality and stable optical performance.
- Fast lead times, low MOQ, and recognized brand fibers help plan procurement reliably.
- Comprehensive test reports and after-sales warranty back product reliability and compliance documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When project timelines and performance matter, Shanghai Weiye OFC Equipment delivers tailored drop solutions with full test documentation.
As a dedicated manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with tight material control. We offer customized service and products for residential/MDU deployments. Every order includes full QA coverage and complete test reports.
Our lab performs high heat, salt-fog, and vibration testing to verify durability. Jacket options cover LSZH, PVC, and PE. Designs cover flat bow-type and figure-8/self-supporting styles and use brand fibers such as Fujikura® and Corning® SMF-28e.
- Controlled production lines and in-process checks for shipments with audit trails.
- Engineering support for specs, trials, and ramp to volume.
- Modern fixturing and calibration minimize variation so every cable meets carrier standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, pairing brand fiber choices with disciplined test flows.
Optical fiber selection and brand options
We select fiber secondary coating line to minimum bend radius, loss, and install environment. Options include OS1, OS2, OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura and Corning SMF-28e are offered to satisfy sourcing standards.
Integrating Strength Members
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is ideal where non-conductivity is necessary. Steel wire adds tensile strength for longer aerial spans and bonding/grounding needs.
Extrusion & Process Control
Jacket options include LSZH for indoor flame safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Closed-loop control of extruder temperature and capstan speed stabilizes line speed and dimensional tolerances.
| Component | Dielectric FRP | Metallic Steel |
|---|---|---|
| Primary use | Non-conductive runs | Aerial spans, high tensile |
| Advantage | Lightweight, inert | Very high tensile strength |
| Installer note | Easier terminations | Bonding/grounding required |
In-Process and Final Testing
Inline geometry/concentricity checks run during manufacturing. Final optical tests verify attenuation and return loss. Each order includes a 100% test report and lab results from high heat, salt-spray, and vibration trials to qualify field handling and drop terminations.
Typical lead times are under 100 km in 4–5 days and 7–10 days for < 500 km. Lot records and first-article approvals support traceability and compliance for U.S. programs.
Our FTTH Drop Cable Types and Structures
Shanghai Weiye OFC Equipment provides a focused portfolio of FTTH drop designs that suit both tight indoor routes and exposed aerial spans. Each option combines tested materials with field-termination geometry and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers/ducts. It keeps bend loss low for simple routing in hallways and MDUs.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs use a messenger element to carry tensile loads. Choose FRP (dielectric) for electrical isolation or steel messenger when bonding/grounding and higher tensile strength are required.
Strength member and core layouts
We provide both dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and flat unitube types balance crush resistance and compact fiber unit for quick termination.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each family is validated for mechanical/optical performance before shipment.
| Design | Best use | Strength element | Jacket |
|---|---|---|---|
| Flat bow-type | Indoor risers, MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting (aerial) | Overhead spans | FRP/Steel | Polyethylene |
| Center loose tube | Higher fiber counts | FRP | LSZH/PE |
| Flat unitube | Low-count, easy strip | FRP/Steel | LSZH/PE |
Production Assets for Speed and Quality
Automation with sensor feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for patch cord prep.
Our production line integrates automated machines that cut and strip drop patch cords to raise throughput and reduce operator variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is ~1.5 s, giving ~20 terminals per minute in production.
Auto Cut & Strip Capabilities
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise stub lengths. Pneumatic cylinder actuators provide quick, repeatable motion and low downtime.
Closed-Loop Control for Repeatability
PLC logic + photoelectric sensors deliver precise positioning and feedback control. Inline checks update SPC charts so operators can correct trends before defects grow.
| Item | Capability | Benefit |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | High throughput |
| Actuation | Cylinder-based | High speed and reliability |
| Material handling | LSZH & PVC; FRP & steel | Accurate stubs, clean terminations |
| Process control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Automated waste ejection and ergonomic loading keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Combined machines, fixtures, and trained staff support FTTH volume targets without compromising accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, reducing cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to raise output and standardize terminal quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC and photoelectric control enable precise detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Cycle time and throughput
Typical operation speed is 1.5s per cycle. This converts to steady throughput under normal production conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to fit common termination hardware.
FRP & Steel Member Handling
The machine cuts FRP/steel strength elements cleanly while protecting adjacent fibers. Customized cutters are offered for nonstandard sizes to maintain precision.
- Automatic waste ejection and sensor-triggered start cut idle time.
- Small footprint (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg mass simplify cell integration.
- Pneumatic cylinders and PLC/photoelectric control improve line reliability and lower maintenance interruptions.
| Specification | Rating | Benefit |
|---|---|---|
| Cycle | ≈1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5–35.0 mm | Compatible with common connectors |
| Stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 helps our production lines meet volume goals without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures each build to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1 to 4 cores with SM or MM fiber. Options include OS1/OS2 plus OM2–OM4 plus G.652D/G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tags.
Jackets, Legends & Branding
Select LSZH/PVC/PE jackets based on route and safety rules. Custom print legends and logos support inventory and warranty tracking.
Length options, packaging, and special structures
Standard reel lengths are 1/2/4 km with custom reels and packaging to fit storage/handling. Choose bow-type flat or self-supporting designs and steel wire or FRP strength members to fit span and isolation requirements.
| Option | Typical | Advantage |
|---|---|---|
| Length | 1, 2, or 4 km | Less staging, easier reels |
| Jacket | LSZH / PE / PVC | Indoor/Outdoor fit |
| Design | Flat bow / Self-supporting | Routing and span flexibility |
As a manufacturer, Shanghai Weiye schedules runs to your plan and provides docs that lists final specifications for straightforward QA on site.
Quality assurance, testing, and documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab runs high-temperature exposure, salt fog corrosion, and vibration tests to qualify materials/assemblies. These tests simulate field stresses for indoor/outdoor applications.
Full Test Reports for Every Reel
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates prevent nonconforming shipments before they leave the factory.
Audit Trail and Compliance
Lot/batch records link tests to reels/serials so audits and claims are easy to verify. Documentation uses standard customer templates to accelerate approvals and receiving inspection.
- In-line checks plus final inspection reduce field failures and lower warranty events.
- QA packages include specifications confirmation and formatted data for rapid review.
- Continuous test trends inform preventive maintenance and raise long-term reliability.
| Trial | Why | Result |
|---|---|---|
| Heat exposure | Thermal stability | Pass at target temperature |
| Salt spray | Corrosion resistance | Qualified for outdoor use |
| Mechanical vibration | Mechanical robustness | Improved field reliability |
Pricing and cost drivers for FTTH drop cable
Budgeting for a drop run begins with fiber/jacket selection and is refined by volume and customization.
Typical prices vary widely—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), length, and design structure.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber grade, jacket material, and the chosen structure for deployment.
Self-supporting designs and steel members increase material/labor. Custom sheath colors/logos/legends add setup and influence price for short runs.
Length/Volume/Customization Impact
Longer reels and higher volume orders lower unit cost. Short runs often carry setup fees and higher unit prices.
- Changeovers and special cutters extend lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment match quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets over phases.
| Factor | Price impact | Guidance |
|---|---|---|
| Optical grade | High impact | Right-size spec to budget |
| Jacket type | Medium | Compare LSZH vs. PE for total cost |
| Length/Volume | Large | Consolidate where possible |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align staffing and sites. Predictable windows cut downtime and help control cost when a rollout is underway.
Typical production windows and capacity planning
Typical production windows are 4–5 days for < 100 km and 7–10 days for < 500 km. We schedule line capacity to match your rollout milestones and to maintain on-time delivery.
The service team provides updates/tracking so installation teams can plan arrivals. For tight schedules, we reserve contingency capacity to pull in critical-path orders.
Why MOQ Matters
The MOQ is 1 km. This reflects line setup such as wire/die adjustments that consume start-up material and scrap.
We review your length and staging plans to select reels to reduce waste/handling. Batch releases can balance inventory with more frequent small-site deliveries.
Installation Scenarios & Readiness
On-site conditions determine whether a self-supporting aerial, ducted pull, or direct burial is the best fit for a project.
Aerial vs Duct vs Direct-Buried
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with appropriate members to control sag and tension for long-term stability.
Duct installations perform best with low-friction jackets and crush-resistant builds so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs need correct burial depth per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor Distribution and ONT
Indoor riser/plenum routes prefer LSZH to meet smoke/flame codes. Flat drop profiles strip clean and present controlled stubs for quick ONT termination.
We advise on steel vs FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware compatibility. Standardized prep from the production line shortens install time and minimizes scrap.
| Scenario | Key feature | Field note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct-buried | PE jacket, moisture barrier | Follow local depth and warning tape rules |
| Interior | LSZH with tight-bend support | Maintain bend radius at wall penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That reduces callbacks, speeds activations, and stable field performance for your system.
Comprehensive Support & After-Sales
Our team coordinates tests, line schedules, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements capture through approved drawings and pilot builds. We provide doc templates and clear install notes so field crews share a unified plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full reports and traceability to support QA acceptance.
- 24/7 availability for status and technical support.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for expedites and urgent changes.
- Configuration control so shipped items match agreed specs consistently.
| Support area | Scope | Outcome |
|---|---|---|
| Engineering | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab trials & 100% test reports | Full traceability |
| Service | Rapid replacement & root-cause | Lower downtime |
Final Thoughts
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel includes a 100% test report and documented trials to support field acceptance in the United States.
A robust production line, including CLX-BPO2-enabled prep machines, reduces variability and shortens turnaround. Our equipment and machines standardize strip and stub lengths so installers get consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance performance and cost to maximize service life. Dedicated support guides scheduling, logistics, and after-sales care so your deployment stays on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every shipment with lab validation and responsive support.
